USB TYPE-C High Speed Digital interface Test Fixture

USB TYPE-C ®

Wilder Alt-Mode solution (DUTC) allows for adjacent USB Type-C® testing by enabling users to switch into selected modes and carry out electrical validation without having to change TPA configuration. The side-by-side design provides a flexible, robust option for DisplayPort™ Certification USB/Thunderbolt Pre-Certification

RESOURCES

User Manual & Specs	DUTC Type-C MC-AC DUTC Type-C MC TBTCAM Type-C Alt-Mode TBTCI Type-C	USB Type-C DisplayPort Type-C USB 3.1 Type-C PD
Mechanical Drawings	TBTCAM Type-C Alt-Mode USB Type C Control Board USB Type C Receptacle USB Type C Plug	DisplayPort Type C Control Board DisplayPort Type C Receptacle DisplayPort Type C Plug USB 3.1 Type-C Power Delivery Coupon

	Model No. USBC-TPA-P USBC-TPA-R USBC-TPA-PR USBC-TPA-RR USBC-TPA-PRR	Part No. 640-0834-000 640-0835-000 640-0836-000 640-0837-000 640-0838-000
	Model No. DUTC-TPA-MC DUTC-TPA-MC-AC TYPE-C-TPA-P TYPE-C-TPA-R	Part No. 640-0839-000 640-0840-000 640-0911-000 640-0912-000
	Model No. USBC-TPA-P USBC-TPA-R USBC-TPA-PR USBC-TPA-RR USBC-TPA-PRR	Part No. 640-0834-000 640-0835-000 640-0836-000 640-0837-000 640-0838-000
	Model No. DPC-TPA-P DPC-TPA-R DPC-TPA-CB DPC-TPA-PR DPC-TPA-PRCB DPC-TPA-RR DPC-TPA-RRCB DPC-TPA-PRRCB DPC-TPA-PCB	Part No. 640-0800-000 640-0801-000 640-0802-000 640-0803-000 640-0804-000 640-0805-000 640-0806-000 640-0807-000 640-0808-000
	Model No. USB3.1-C-USDS USB3.1-C-ELD USB3.1-C-PDC USB3.1-C-PDCK USB3.1-C-SPDC	Part No. 415-0071-000 415-0072-000 640-0760-000 640-0761-000 640-0762-000
